Choosing Your SQD Tool - SQD Documentation

This guide helps you understand the differences between SQD’s three offerings and choose the right tool for your project.

Overview: Three Ways to Access Blockchain Data

SQD provides three tools for working with blockchain data, each serving different use cases:

Portal API - Direct HTTP access to raw blockchain data
Pipes SDK - Lightweight streaming library for custom data pipelines
Squid SDK - Complete framework with built-in PostgreSQL and GraphQL

How They Work Together

Portal data flow showing raw blockchain data being transformed by SDK and stored in your database

Portal provides the raw blockchain data through HTTP API
SDKs (Pipes and Squid) use Portal as their data source and add:
- Event and transaction decoding
- Type-safe data transformation
- Batch processing capabilities
- Database persistence
- Real-time data ingestion

Both SDKs use Portal under the hood. When you use an SDK, you’re still accessing blockchain data through Portal—the SDK just makes it easier to work with.

Raw API vs SDKs

Portal and SDKs serve different use cases in the blockchain data indexing pipeline.

Portal: Direct Data Access

Portal provides raw blockchain data access through a simple HTTP API. You query specific blocks, transactions, logs, or traces and receive the raw data directly.

curl --compress -X POST 'https://portal.sqd.dev/datasets/ethereum-mainnet/stream' \
  -H 'Content-Type: application/json' \
  -d '{
    "type": "evm",
    "fromBlock": 18000000,
    "toBlock": 18001000,
    "fields": {
      "log": {
        "address": true,
        "topics": true,
        "data": true
      }
    },
    "logs": [{
      "address": ["0xA0b86991c6218b36c1d19D4a2e9Eb0cE3606eB48"]
    }]
  }'

SDKs: Data Transformation Frameworks

SDKs (Pipes and Squid) build on top of Portal to provide data transformation, decoding, and persistence capabilities.

import { createTarget } from "@subsquid/pipes";
import { evmPortalSource, EvmQueryBuilder } from "@subsquid/pipes/evm";

const queryBuilder = new EvmQueryBuilder()
.addFields({ block: { number: true, hash: true }, log: { data: true } })
.addLog({
  request: { address: ["0xa0b86991c6218b36c1d19d4a2e9eb0ce3606eb48"] },
  range: { from: 20000000, to: 20001000 }
});

const source = evmPortalSource({
portal: "https://portal.sqd.dev/datasets/ethereum-mainnet",
query: queryBuilder
});

const target = createTarget({
write: async ({ read }) => {
  for await (const { data } of read()) {
    // Transform and persist to your database
  }
}
});

await source.pipeTo(target);

Detailed Comparison

Aspect	Portal	SDKs (Pipes/Squid)
Purpose	Raw data retrieval	Data transformation and persistence
Output	Raw blockchain data (JSON)	Processed data in databases/APIs
Performance	10-50x faster than RPC	Additional processing overhead
Setup Complexity	Minimal (HTTP requests only)	Project scaffolding, TypeScript required
Data Decoding	Manual (you handle ABI decoding)	Built-in ABI decoding
Database	Bring your own	PostgreSQL (Squid), custom (Pipes)
GraphQL API	Not included	Auto-generated (Squid only)
Type Safety	Limited (JSON responses)	Full TypeScript support
State Management	Manual	Built-in with fork handling
Best For	Analytics, data lakes, custom pipelines	dApps, APIs, traditional backends
Languages Supported	Any (HTTP API)	TypeScript
Learning Curve	Low (HTTP + your language)	Medium (TypeScript + framework concepts)

When to Use Portal

Data Analytics

Stream raw data directly into analytics platforms like ClickHouse, BigQuery, or Snowflake

Custom Pipelines

Build data pipelines in Python, Go, Rust, or any language with HTTP support

Data Lakes

Populate data warehouses with raw blockchain data for long-term analysis

Rapid Prototyping

Quick experiments without setting up a full indexing framework

When to Use SDKs

dApp Backends

Build GraphQL APIs that power decentralized applications

Complex Transformations

Decode events, track relationships, and maintain state across blocks

Production APIs

Deploy scalable indexers with built-in monitoring and deployment tools

Type Safety

Leverage TypeScript for compile-time safety and better developer experience

Pipes SDK vs Squid SDK

Both SDKs consume data from Portal but offer different levels of abstraction and flexibility.

Architecture Differences

Pipes SDK
Squid SDK

Streaming Library ApproachPipes SDK is a lightweight streaming library that gives you maximum flexibility:

You define the data flow using a pipe-and-target pattern
You bring your own database and persistence logic
You control exactly how data is processed and stored
No CLI tools or scaffolding - integrate into existing projects

// Minimal setup - you control everything
const source = evmPortalSource({ portal: url, query });
const target = createTarget({ write: yourCustomLogic });
await source.pipeTo(target);

Complete Framework ApproachSquid SDK is a full-featured framework with built-in conventions:

CLI tools for project scaffolding and management
PostgreSQL database with automatic migrations
Auto-generated GraphQL API from schema
Built-in deployment tools for SQD Cloud

// Opinionated structure with built-in features
const processor = new EvmBatchProcessor()
  .setGateway(url)
  .addLog({ ... });

const db = new TypeormDatabase();
processor.run(db, async (ctx) => {
  // Framework handles state, rollbacks, persistence
});

Feature Comparison Matrix

Feature	Pipes SDK	Squid SDK
Type	Streaming library	Complete framework
Installation	`npm install @subsquid/pipes`	`npm i -g @subsquid/cli`
Project Setup	Manual integration	CLI scaffolding (`sqd init`)
Database	Bring your own (any)	PostgreSQL (built-in)
GraphQL API	Not included	Auto-generated from schema
Migrations	You implement	Auto-generated
Type Generation	Manual	Auto-generated from ABI and schema
Event Decoding	Built-in codec	Built-in codec
State Rollbacks	You implement	Built-in fork handling
CLI Tools	None	Full CLI suite
Cloud Deployment	Manual	`sqd deploy` command
Local Development	Standard Node.js	Docker Compose included
Data Targets	Custom (you implement)	TypeORM, BigQuery, CSV, JSON, Parquet
Real-time Support	Yes (streaming)	Yes (unfinal blocks)
Best For	Custom pipelines, flexibility	Full-stack dApps, rapid development
Learning Curve	Lower (simpler API)	Higher (more concepts)
Bundle Size	Smaller	Larger (includes framework)
Customization	Maximum flexibility	Opinionated but extensible

Decision Matrix

Choose Pipes SDK
Choose Squid SDK

You should use Pipes SDK if:

✅ You want maximum flexibility and control
✅ You’re integrating into an existing codebase
✅ You want to use a specific database (MongoDB, ClickHouse, etc.)
✅ You don’t need a GraphQL API
✅ You prefer lightweight dependencies
✅ You want to build custom data pipelines
✅ You’re experienced with database design and management

Example use cases:

Real-time dashboards with custom databases
Data pipelines feeding multiple systems
Microservices that need blockchain data
Custom analytics engines

Why We Built Pipes SDK

Pipes SDK represents a fundamental rethinking of how blockchain indexing SDKs should work, informed by years of experience with Squid SDK 1.0 and feedback from the developer community.

Challenges with Squid SDK 1.0

While Squid SDK 1.0 successfully served many production use cases, we identified several architectural limitations that hindered developer experience and community adoption:

Tight Coupling and Complexity

Although designed with modularity in mind, many components became tightly coupled in practice. This made it extremely difficult to replace or extend parts of the system without understanding the entire SDK’s internal workings, creating a steep learning curve for developers attempting customization.

Lack of Documentation and Tests

Insufficient documentation and internal test coverage made introducing changes risky and time-consuming. Developers faced significant friction when trying to extend or modify the SDK’s behavior.

Standalone Design Limitations

The SDK was built to function as a standalone process, making it challenging to embed into existing applications or workflows. This architectural decision limited flexibility for teams wanting to integrate blockchain indexing into their existing codebases.

Rigid and Opinionated Approach

The framework enforced a very opinionated development style with limited room for customization. Developers often found themselves constrained by the SDK’s assumptions rather than supported by its abstractions.

No Client-Side Testing Framework

The absence of a built-in testing framework for client applications increased friction for developers who needed to validate their integrations and business logic.

Limited Community Adoption

These combined limitations significantly hindered external contributions, resulting in minimal meaningful engagement from the developer community.

Pipes SDK Design Goals

Pipes SDK was built from the ground up to address these challenges and provide a modern, flexible foundation for blockchain data indexing:

Focus on Business Logic

Enable developers to concentrate on application-specific business logic rather than dealing with low-level blockchain implementation details.

Code Reusability

Promote code sharing and maintainability by extracting common functionality into reusable, composable packages.

Built-in Extensions

Provide ready-to-use extensions for common tasks including Portal caching layers, factory contract handling, and database integrations (PostgreSQL, ClickHouse, Kafka).

Community-Friendly Architecture

Design a plugin system that makes it easy for developers to create and share extensions, fostering a vibrant ecosystem of community contributions.

Better Observability

Include first-class support for custom metrics, profiling tools, and centralized logging services to help developers monitor and optimize their indexers.

Modern Runtime Support

Ensure compatibility with modern JavaScript runtimes like Bun for faster development and improved performance.

Pipes SDK maintains backward compatibility with Squid SDK’s data sources (Portal) while offering a completely redesigned developer experience focused on flexibility, composability, and ease of use.

Key Benefits by Tool

Portal API Benefits

Language Agnostic - Use any programming language with HTTP support
Minimal Setup - Start querying in minutes with simple HTTP requests
Maximum Control - Full control over data processing and storage
High Performance - 10-50x faster than RPC for historical data

Pipes SDK Benefits

Lightweight - Minimal dependencies and bundle size
Flexible - Use any database or data target
Streaming - Built-in backpressure handling and memory efficiency
Type-Safe - Full TypeScript support with auto-generated types

Squid SDK Benefits

Complete Solution - Everything you need in one framework
Rapid Development - CLI tools and scaffolding for quick starts
Auto-Generated APIs - GraphQL API generated from your schema
Production Ready - Built-in deployment, monitoring, and scaling tools
Comprehensive Tooling - Hot reload, migrations, type generation

Next Steps

Now that you understand the differences, choose your path:

Try Portal

Start querying raw blockchain data in minutes

Try Pipes SDK

Build a lightweight data pipeline

Try Squid SDK

Create a full-featured indexer with GraphQL API
